Minimal design
The VMC disappears into the wall enhancing the visual streamlining of the wall. No visible vent on the outside. For a design that is faithful to the "less is more" principle.
INGENIUS VMC GHOST integrated window systems
The integrated window systems with a forced mechanical ventilation system that disappears completely, invisible both inside and outside the building. Perfect also for historic or prestigious buildings.
- Maximum aesthetic impact
- Comfort and health
- Home automation integration
Comfort
Elegance is invisible
An innovative solution for those seeking a minimally invasive technology that can significantly improve indoor wellness. An integrated window systems with a Controlled Mechanical Ventilation system that is concealed within the wall, leaving only the small touch display of the controls visible. No machinery, plate or encumbrance. The external appearance of the façade is also preserved, with air intake and exhaust vents hidden in the window case.
Pure air without dispersions
Even with its minimal aesthetic impact, INGENIUS VMC GHOST maintains the functionality of the integrated window systems and the Alpac VMC component. Indeed, it becomes possible to improve the insulation and energy performance of the enclosure, with a recovery of thermal energy of up to 91%. It also ensures there is a constant ventilation of the rooms, and enhances the indoor comfort by purifying the incoming air from pollen and fine particulate matter PM10 and PM2.5.
Characteristics and benefits
Ultra silent
Imperceptible silent operation. A sound pressure level at minimum speed of just 18 decibels.
First rate heat recovery
Efficiency of thermal recovery up to 91% certified by TÜV SÜD.
Very simple maintenance
The replacement of the filter is made easy thanks to a special cover in the window case that can be removed by the user.
Accessories
Sensors
Controls
Filters
Pure air, intelligent operation
Each ventilation unit integrated in the INGENIUS integrated window systems can be fitted with optional sensors for the constant and automatic control of the air quality in every room.
The hygrometer sensor measures the degree of humidity in the air, a factor that greatly influences the feeling of wellness and liveability.
Special CO2 and VOC sensors act as sentinels for the presence of carbon dioxide and volatile pollutants, intelligently and automatically regulating the operation of each VMC. In this way it is possible to prevent buildups and guarantee optimal conditions of healthiness in the indoor air.
Comfort has never been so smart
Alpac home automation solutions allow you to manage each INGENIUS mechanical ventilation device using a smartphone and tablet.
The Alpac AIR smart app, available in Apple and Google stores, has been designed for the integrated management of Alpac VMC systems. It allows you to constantly keep an eye on the data concerning the air quality in the home, to increase or decrease the air flow and to manage the comfort conditions room by room with the utmost simplicity.
In addition, Alpac home automation allows you to set up specific scenarios to maximise the well-being of the environment and optimise energy savings, synergistically managing mechanical ventilation, lowering blinds and lights.
Excellent filtration, easy maintenance
Each VMG INGENIUS is equipped with an F7 filter as standard. This high-performance mechanical filter provides excellent protection against airborne pollutants such as PM10 and PM2.5 fine particles, pollen and allergens. It is the system that alerts you when the filter is spent and needs changing (once a year on average). The replacement of the filter is an extremely simple operation and something that can be carried out by the user.
